自動焊接設備的正確打開方式，主要是包括兩個步驟，一是正確的操作方法，二是日常的維護保養辦法。記住這兩條就可以大大提高工作效率，節約企業的生產成本了。下面山東自動焊接設備廠家就來為您講解吧。

The correct opening method of automatic welding equipment mainly includes two steps, one is the correct operation method, and the other is the daily maintenance method. Keeping these two points in mind can greatly improve work efficiency and save production costs of enterprises. Next, Shandong automatic welding equipment manufacturer will explain to you.

一、自動焊接設備操作方法：

1、 Operation method of automatic welding equipment:

1，根據產品規格更換焊頭，和一焊接夾具的CP線。

1. Replace the welding head and CP line of a welding fixture according to the product specification.

2，調整好兩焊頭間相焊接的壓力和間距，兩焊頭間距以不損傷以及電容芯子端面需要為準。

2. Adjust the pressure and spacing of phase welding between the two welding heads. The spacing between the two welding heads shall be subject to the requirements of no damage and the end face of the capacitor core.

3.調節焊接電壓控制焊接電流大小，一般在30V左右..

3. Adjust the welding voltage to control the welding current, generally around 30V

4.調整調整鈕(1)調整焊接速度適當位置。

4. Adjust the adjusting knob (1) to adjust the welding speed to the proper position.

5，調節旋鈕調節所述振動電容器的輸送速度中度的軌道位置。

5. Adjust knob (b) to adjust the conveying speed of the vibrating capacitor to a moderate rail position.

6，焊機工作時間進行設定：0.1S。

6. Set the working time of the welding machine: 0.1S.

7，在0.5MPa的壓力控制。

7. Control the pressure at 0.5MPa.

8、調節工作結束即可開始通過焊接。

8. After the adjustment, the welding can be started.

9.在操作中發現異常應立即切斷電源，通知維修人員進行維修..

9. In case of any abnormality during operation, immediately cut off the power supply and notify the maintenance personnel for maintenance

10.每天結束時，關閉電源和空氣，清潔和維護設備。

10. At the end of each day, turn off the power and air, clean and maintain the equipment.

二、自動焊接設備的維護

2、 Maintenance of automatic welding equipment

1，主機中各活動主要部位的導軌系統須進行加注高溫黃油(300℃)，周期為每星期只有一次。

1. The guide rail system of the main moving parts in the main engine must be filled with high-temperature grease (300 ℃), and the cycle is only once a week.

2，刷切耳機的耳機和共軌潤滑脂填充循環每周一次。

2. Brush and cut the earphones and fill them with common rail grease once a week.

3，夾具教學活動導桿部位進行加注機油潤滑，夾具可靈活運用動作即可。

3. The fixture teaching guide rod shall be lubricated with oil, and the fixture can be flexibly used.

4.檢查夾具的四個定位銷，如果定位銷的定位面卡有引線，須及時清理，否則會影響鑄焊質量..

4. Check the four locating pins of the fixture. If the locating surface of the locating pin is stuck with leads, it must be cleaned in time, otherwise the casting and welding quality will be affected

5，檢查夾具的四個發展定位銷的焊接點，此焊點因長期使用后成為可能導致出現資金斷裂。若有斷裂，焊接后即可進行正常工作使用。

5. Check the welding points of the four development positioning pins of the fixture. This welding point may lead to capital fracture after long-term use. If there is any fracture, it can be used for normal work after welding.

6，檢查在水中三重氣體源在玻璃中，如果水位超過紅線，須將水排出。

6. Check that the triple gas source in the water is in the glass. If the water level exceeds the red line, the water must be discharged.

7、檢查氣源三聯件中的油杯中的油，若油位低于成本低線，須進行加注說明機油(油霧器的滴油量為10秒/滴)。

7. Check the oil in the oil cup in the air supply triplet. If the oil level is lower than the low cost line, fill the oil (the oil drip volume of the oil mist is 10 seconds/drop).

8，檢查在水箱中的水位，水位高于高線或小線之下，被要求停止使用設備

8. Check the water level in the water tank. If the water level is higher than the high line or lower than the small line, the equipment is required to stop using

綜上所述，自動焊接設備的兩大類正確打開方式，操作和維護保養細則要重視起來，就給大家介紹完畢了，大家是不是又學到了不少東西呢?如果大家還有什么不明白的地方，可以在網站http://www.fx361.com.cn聯系我們，也可以打電話咨詢。

To sum up, we should pay more attention to the operation and maintenance rules of the two main types of correct opening methods of automatic welding equipment, and then introduce them to you. Have you learned a lot? If there is anything you don't understand, you can visit the website http://www.fx361.com.cn Contact us or call us for consultation.
