山東數控焊接設備的3個裝置
來源：http://www.fx361.com.cn/ 發布時間：2021-12-09 瀏覽次數：0
通用焊接設備在我們生活中的應用是非常廣泛的，具有通用性強、操作簡單、經久耐用等特點，那么它的結構特點有哪些呢？下面通用焊接設備廠家來為大家做一下詳細的講解：
General welding equipment has a wide range of applications in our lives. It has the characteristics of strong versatility, simple operation, and durability. So what are its structural characteristics? The following general welding equipment manufacturers will give you a detailed explanation:
General welding equipment has a wide range of applications in our lives. It has the characteristics of strong versatility, simple operation, and durability. So what are its structural characteristics? The following general welding equipment manufacturers will give you a detailed explanation:
1. 機械裝置
1. Mechanical device
1. Mechanical device
通用焊接設備的點焊機系統由機械裝置、供電裝置、控制裝置三大部分組成。通常狀態為焊鉗短行程張開，當把控制按鈕切換到“通電”位置，扣動手柄開關則焊鉗夾緊加壓，同時電流在控制系統控制下完成一個焊接周期后恢復到短行程張開狀態。
The spot welding machine system of general welding equipment is composed of three parts: mechanical device, power supply device, and control device. The normal state is that the welding tongs are opened for a short stroke. When the control button is switched to the "power on" position, the handle switch is pressed to clamp and pressurize the welding tongs. At the same time, the current returns to the short stroke after completing a welding cycle under the control of the control system. Open state.
2. 供電裝置
2. Power supply device
2. Power supply device
主電力電路由電阻焊變壓器、可控硅單元、主電力開關、焊接回路等組成。焊鉗的強度、剛度、發熱要滿足一定要求，并且要具有良好的導電和導熱性，同時要求焊鉗采用通水冷卻，所以選擇焊鉗電極臂能夠承受400kg壓力的新型焊鉗。
The main power circuit is composed of resistance welding transformer, thyristor unit, main power switch, welding circuit, etc. The strength, rigidity, and heat generation of the welding tongs must meet certain requirements, and it must have good electrical and thermal conductivity. At the same time, the welding tongs are required to be cooled by water. Therefore, a new type of welding tongs that can withstand a pressure of 400kg is selected for the electrode arm of the welding tongs.
3. 控制裝置
3. Control device
3. Control device
控制裝置主要提供信號控制電阻焊機動作接通和切斷焊接電流，控制焊接電流值，進行故障監測和處理。
以上就是山東數控焊接設備為大家介紹的通用焊接設備的結構特點，希望通過上面的介紹能夠?qū)Υ蠹矣幸恍?shí)質性的幫助，如果還想了解更多信息可以直接關注我們公司網址。
The control device mainly provides signals to control the action of the resistance welding machine to turn on and off the welding current, control the value of the welding current, and perform fault monitoring and handling.
The above is the structural characteristics of the general welding equipment introduced by Shandong CNC welding equipment. I hope that the above introduction can give you some substantial help. If you want to know more information, you can directly follow our company website.
